Start With the Equipment List, Then Draw the Cable Plan
Clinics do not fail because of the network in general. They fail at a specific machine in a specific room on a specific morning. So the first document on a veterinary or medical project is not a floor plan, it is a list: every device that needs a connection, what it actually requires, and what happens to the schedule when it stops working. KSEDCO builds low-voltage infrastructure for practices across Georgia, from single-doctor clinics to multi-suite specialty buildings, and this list drives everything that follows.
Room by Room
Exam and treatment rooms
Wall plates positioned for how the room is actually used rather than where the drywall was convenient. Practices that chart in the room need a stable wired path for the workstation, plus drops for a printer, a label printer and a phone. Anything mounted near a sink or a wet table needs a plate location that will not be sprayed during cleaning.
Imaging
Digital radiography, ultrasound and CT rooms deserve a wired connection rather than wireless, and a pathway planned before the room is built. Lead-lined walls and shielded rooms are difficult to penetrate after the fact, and the penetration itself has to be handled correctly. Image transfer to the practice management system is the workflow bottleneck people notice, so we size that path deliberately.
Kennels, wards and wash-down areas
This is the part of a veterinary building that ordinary commercial cabling handles badly. Runs are hosed down, humidity is constant, and there is chemical exposure from disinfectants. Terminations belong in sealed enclosures rated for wet locations, cameras and access devices get gasketed housings, and cable pathways stay out of the spray zone entirely. A standard indoor box in a kennel corridor will corrode.
Front desk and waiting
Check-in workstations, payment terminals, phones and client Wi-Fi all converge on a small counter. Client wireless rides a separate path from clinical devices, both for performance in a full waiting room and to keep a public network away from clinical systems.
The closet
Small practices tend to grow a rack in a utility room next to a water heater. If we are involved at buildout, the equipment gets a lockable enclosure in a room with real cooling and no plumbing overhead, because the recovery cost of a leak above the rack dwarfs the cost of moving it.
What Compliance Asks of the Physical Layer
HIPAA does not specify cable types. What it does require is control over access to systems holding protected health information, and part of that control is physical: a locked enclosure, labeled and documented ports, unused jacks left unpatched, and clinical systems kept off the public wireless. Practices taking card payments carry PCI DSS obligations on top, which again come down to keeping payment traffic on a documented and separated path. Getting this right during installation is far easier than retrofitting it during an assessment.
Staying Up Through a Georgia Summer
Afternoon thunderstorms are routine across the state from late spring through summer, and coastal and south Georgia practices carry hurricane exposure on top of that. Two things follow. First, any copper that leaves the building for an outdoor camera, a gate or a detached kennel building gets surge protection at the entrance, bonded properly. Second, the equipment rack needs UPS capacity sized for a real ride-through and a clean shutdown, not just a few seconds of coverage. A brief outage in the middle of an imaging study costs more than the equipment protecting against it.
Handover
Certified test results for every link, a port map keyed to room names your staff already uses, rack photos, and a labeled patch field. When a piece of diagnostic equipment goes quiet, the practice manager should be able to tell a technician exactly which port it lives on.
